2 Inch A - Axis Sapphire Wafer Radiation Resistance For Epi - Ready Test

I'm Online Chat Now

2 Inch A - Axis Sapphire Wafer Radiation Resistance For Epi - Ready Test

China 2 Inch A - Axis Sapphire Wafer Radiation Resistance For Epi - Ready Test supplier
2 Inch A - Axis Sapphire Wafer Radiation Resistance For Epi - Ready Test supplier 2 Inch A - Axis Sapphire Wafer Radiation Resistance For Epi - Ready Test supplier 2 Inch A - Axis Sapphire Wafer Radiation Resistance For Epi - Ready Test supplier

Large Image :  2 Inch A - Axis Sapphire Wafer Radiation Resistance For Epi - Ready Test

Product Details:

Place of Origin: china
Brand Name: zmsh
Model Number: A-plane 2INCH

Payment & Shipping Terms:

Minimum Order Quantity: 25pcs
Price: by case
Packaging Details: Vacuum-sealed containers with nitrogen backfill in a class 100 environment
Delivery Time: 15-20days
Supply Ability: 1000pcs/months
Contact Now
Detailed Product Description
Material: 99.999% Al2O3 Industry: Led,optical Glass,epi-ready Wafer
Application: Semicondutor Wafer, Led Chip, Optical Glass Window, Electronic Ceramics Color: White Or Red Or Blue
Vision Light Transmissivity: 85% Advantagement: High Hardness9.0,wear Resistance,
Type: 2inch A-axis Thickness: 0.43mm

A-axis sapphire wafer for epi-ready test,sapphire optical chips, 2inch A-axis sapphire epi-ready,2inch sapphire substrates for led


Sapphire Indtroduce

Product Name: Aluminum oxide (Al2O3) crystal substrate Sapphire crystal
Product Description: Al2O3 single crystal (Sapphire, also known as white stones, sapphire) has good thermal properties, excellent electrical characteristics and dielectric properties, and anti-chemicalcorrosion, it is high temperature, thermal conductivity, high hardness, infrared transparent, chemically stable good. Widely used in high-temperature infrared window materials and III-V nitride epitaxial film substrate and a variety of materials to meet the growing blue, purple, white light-emitting diode (LED) and blue laser (LD) needs, Branch Crystal company specializing in the production of high quality polished sapphire crystal and epitaxial substrates will provide you with a lot of high quality and low price monocrystalline substrate.
Technical parameters:

Crystal structure Hexagonal a = 4.758 Å c = 12.992 Å
Crystal orientation

(11-20) - a plane: 2.379 Å          (1-102) - r plane: 1.740 Å

(10-10) - m plane: 1.375 Å          (0001) - c plane: 2.165 Å
Crystal purity > 99.999%
Mp 2040 o C
Density 3.98 g / cm 3
Hardness 9 (mohs)
Thermal expansion 7.5 (x10 -6 / o C)
Heat capacity 0.10 (cal / o C)
Thermal conductivity 46.06 @ 0 o C 25.12 @ 100 o C, 12.56 @ 400 o C (W / (mK))
Permittivity ~ 9.4 @ 300K at A axis ~ 11.58 @ 300K at C axis
Loss tangent <2x10 -5 at A axis, <5 x10 -5 at C axis
Specifications:

C, A, M, R Tolerance: + / -0.2 degrees

dia2"~dia dia15" x 250mm

Single throw or double throw, Ra <5A

Note: according to customers' requirements and size of the corresponding direction.

Standard Packaging: 1000 clean room, 100 clean bag or single box packaging
2 Inch A - Axis Sapphire Wafer Radiation Resistance For Epi - Ready Test
specification description
Material: Single crystal Al2O3 99.999%

2 Inch A - Axis Sapphire Wafer Radiation Resistance For Epi - Ready Test

Orientation: A-axis 0.2°

Diameter:50.8.±0.2mm

Thickness :430±15um or 330±15um

Primary flat:16±1mm

OF Orientation flat: OFF C axis±0.1° C-plane(0001)



Frontside Surface Roughness:Ra<0.2nm

Backside Surface Roughness: 0.8~1.2um

( Or double side polished,  both side Ra<0.2nm)



TTV:<10um

BOW:-10~0um

WARP:<10um



Laser Mark Series No. by needs

Package:Vacuum-sealed containers with nitrogen backfill in a class 100 environment

Cleanliness :Free visible contamination

If needing, 3-6inch A-axis wafers also can be provided.
