Large Image :  Aluminum Oxide Crystal Sapphire Rods Wear Resistance For Iphone Camera Glass

Product Details:

Place of Origin: china
Brand Name: zms
Model Number: lens-028

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: by case
Packaging Details: carton case
Delivery Time: 2-4weeks
Payment Terms: L/C, T/T
Supply Ability: 500pcs/month
Contact Now
Detailed Product Description
Vision Light Transmissivity: 85% Industry: Electronic Product Protect Glass Cover,led,optical Glass,epi-ready Wafer
Materials: 99.999% Al2O3 Color: Colorless Transparent
Advantagement: Hardness 9.0,wear Resistance, Applications User: Iphone Camera Glass,phone,protect Window
Orientation: Cor A-axis

OME sapphire optical glass window,Al2O3 sapphire lens for window ,sapphire glass,sapphire led substrates .sapphire wafer

1. sapphire Introduce

Product Name: Aluminum oxide (Al2O3) crystal substrate Sapphire crystal rod
Product Description: Al2O3 single crystal (Sapphire, also known as white stones, sapphire) has good thermal properties, excellent electrical characteristics and dielectric properties, and anti-chemicalcorrosion, it is high temperature, thermal conductivity, high hardness, infrared transparent, chemically stable good. Widely used in high-temperature infrared window materials and III-V nitride epitaxial film substrate and a variety of materials to meet the growing blue, purple, white light-emitting diode (LED) and blue laser (LD) needs, Branch Crystal company specializing in the production of high quality polished sapphire crystal and epitaxial substrates will provide you with a lot of high quality and low price monocrystalline substrate.
Technical parameters:

Crystal structure Hexagonal a = 4.758 Å c = 12.992 Å
Crystal orientation

(11-20) - a plane: 2.379 Å (1-102) - r plane: 1.740 Å

(10-10) - m plane: 1.375 Å (0001) - c plane: 2.165 Å
Crystal purity > 99.99%
Mp 2040 o C
Density 3.98 g / cm 3
Hardness 9 (mohs)
Thermal expansion 7.5 (x10 -6 / o C)
Heat capacity 0.10 (cal / o C)
Thermal conductivity 46.06 @ 0 o C 25.12 @ 100 o C, 12.56 @ 400 o C (W / (mK))
Permittivity ~ 9.4 @ 300K at A axis ~ 11.58 @ 300K at C axis
Loss tangent <2x10 -5 at A axis, <5 x10 -5 at C axis
Specifications:

C, A, M, R Tolerance: + / -0.2 degrees
dia2"~dia dia10" x 250mm
Single throw or double throw, Ra <5A
Note: according to customers' requirements and size of the corresponding direction.

Standard Packaging: 1000 clean room, 100 clean bag or single box packaging


2. Applications on sapphire optical &sapphire substrates

Common applications

Window

Synthetic sapphire—sometimes referred to as sapphire glass—is commonly used as a window material, because it is both highly transparent to wavelengths of light between 150 nm (UV) and 5500 nm (IR) (the visible spectrum extends about 380 nm to 750 nm, and extraordinarily scratch-resistant.

The key benefits of sapphire windows are:

  • Very wide optical transmission band from UV to near-infrared, (0.15–5.5 µm)
  • Significantly stronger than other optical materials or standard glass windows
  • Highly resistant to scratching and abrasion (9 on the Mohs scale of mineral hardness scale, the 3rd hardest natural substance next to moissanite and diamonds)
  • Extremely high melting temperature (2030 °C)

Single crystal sapphire boule grown by the Kyropoulos method.

The sapphire windows are used in both high pressure and vacuum chambers for spectroscopy, crystals in various watches, and windows in grocery store barcode scanners since the material's exceptional hardness and toughness makes it very resistant to scratching.

It is used for end windows on some high-powered laser tubes as its wide-band transparency and thermal conductivity allow it to handle very high power densities in the infra-red or UV spectrum without degrading due to heating.

Along with zirconia and aluminium oxynitride, synthetic sapphire is used for shatter resistant windows in armored vehicles and various military body armor suits, in association with composites.


3. Windows general specifications

Diameter                 0.2-300mm
Diameter tolerance +/-0.1mm or +/-0.02mm
Thickness               0.10-200mm
Thickness tolerance ± 0.1mm or +/-0.01mm
Surface quality (scratch & dig) 60/40, 40/20 or better
Surface accuracy   λ/4 , λ/2,  λ
Clear Aperture        >85%, >90%
Parallelism             +/-3' ,+/-30''
Bevel                      0.1~0.3mm×45 degree
orientation              A.,R,M,C-Plane


About sapphire produce flow
Aluminum Oxide Crystal Sapphire Rods Wear Resistance For Iphone Camera Glass ⇒ Aluminum Oxide Crystal Sapphire Rods Wear Resistance For Iphone Camera Glass⇒ Aluminum Oxide Crystal Sapphire Rods Wear Resistance For Iphone Camera GlassAluminum Oxide Crystal Sapphire Rods Wear Resistance For Iphone Camera Glass
crystal  body--> ingot/block in customized axis--->wire saw cut--->lapped & polish--->Inspection



4. Our products

Aluminum Oxide Crystal Sapphire Rods Wear Resistance For Iphone Camera Glass

About ZMKJ company Introduce

SHANGHAI FAMOUS TRADE CO.,LTD. locates in the city of Shanghai, Which is the best city of China, and our factory is founded in Wuxi city in 2014.
We specialize in processing a varity of materials into wafers, substrates and custiomized optical glass parts.components widely used in electronics, optics, optoelectronics and many other fields. We also have been working closely with many domestic and oversea universities, research institutions and companies, provide customized products and services for their R&D projects.
It's our vision to maintaining a good relationship of cooperation with our all customers by our good reputatiaons.
so we also can provide some other materials semiconductor wafers as like below
Aluminum Oxide Crystal Sapphire Rods Wear Resistance For Iphone Camera Glass
