Dia 50.8mm Size IC Silicon Wafer , N Type 300mm Silicon Wafer Si Single Crystal Material

I'm Online Chat Now

Dia 50.8mm Size IC Silicon Wafer , N Type 300mm Silicon Wafer Si Single Crystal Material

China Dia 50.8mm Size IC Silicon Wafer , N Type 300mm Silicon Wafer Si Single Crystal Material supplier
Dia 50.8mm Size IC Silicon Wafer , N Type 300mm Silicon Wafer Si Single Crystal Material supplier Dia 50.8mm Size IC Silicon Wafer , N Type 300mm Silicon Wafer Si Single Crystal Material supplier

Large Image :  Dia 50.8mm Size IC Silicon Wafer , N Type 300mm Silicon Wafer Si Single Crystal Material

Product Details:

Place of Origin: china
Brand Name: zmkj
Model Number: si-2inch

Payment & Shipping Terms:

Minimum Order Quantity: 25pcs
Price: by case
Packaging Details: 25pcs casstle in 100-grade cleaning room
Delivery Time: 5-30days
Contact Now
Detailed Product Description
Material: Si Single Crystal Industry: IC Semicondctor Wafer,solor ,optical Glass
Application: IC, Solor Wafer,optical Lens, Size: Dia50.8mm
Method: Cz,Fz Type: Dopant: P(B), N(P)
Grade: Prime Grade/test Grade

n-type 2inch prime sillicon wafer, sillicon optical lens, IC sillicon substrates  , poly sillicon wafer,Semiconductor 3' inch silicon wafer, single crystal ,2inch, 3inch,4inch,5inch,6inch,8inch,12inch  silicon wafer, single side polished silicon wafer



1. Description

Si is most widely used for lenses and windows in IR systems operating in the 2 - 12 µm range. The enviroment does not make any problems because Germanium is inert, mechanically rugged, and fairly hard. It is an excellent choice for multi-spectral systems and for applications where EMI shielding is necessary. Germanium can be electrically heated for anti-fogging or anti-icing applications. We do not manufacture Germanium, but hold stock of Czochralsky grown material of various diameters. It can be used as a polycrystalline or as a single crystal. The purity should correspond to an electrical resistivity of at least 20 to 30 Ohm/cm, either p- or n-type to avoid absorption bands. The high retractive index makes AR-coating essential.
Silicon (Si) is commonly used as a substrate material for infrared reflectors and windows in the 1.5 - 8 µm region. The strong absorption band at 9 µm makes it unsuitable for CO2-laser transmission applications, but it is frequently used for laser mirrors because of its high thermal conductivity and low density. Silicon is also a usefull transmitter in the 20 µm range.





Density

2.4(g/cm3)
Dope type no dope doped B doped P
Type              I     P   N
resistivity Ø 1000Ωcm 10-3~40Ωcm 10-3~40Ωcm
E P D ≤100∕cm2 ≤100∕cm2 ≤100∕cm2
Oxygen content (∕cm3) ≤1~1.8×1018 ≤1~1.8×1018 ≤1~1.8×1018
Carbon content(∕cm3) ≤5×1016 ≤5×1016 ≤5×1016
Size 10×3m,10×5m,10×10mm,15×15mm,
Dia50.8mm,Dia76.2mm,Dia100mm  dia6-12inch
or by customized size
thickness 0.5mm,1.0mm or other
tolerance <±0.1mm
thickness tolerance <±0.015mm (or <±0.005mm)
surface 1sp or 2sp
orientation ±0.5°

orientation <100>,<110>,<111>
package 100grade in1000 grade cleaning room



2. Specification 2 Inch  Silicon Wafers

Product Name
Silicon Wafer 2 inch
Diameter
50.8+/-0.3mm
Thickness
279+/-25um/Customized
Conductivity Type
N/P
Resistivity
Customized
Growth Method
CZ/FZ
Orientation
100/111
Surface
Single side polished/Double side polished/ Grinding
TTV
<10 um
Bow/Warp
< 30 um
Carbon Content
18 ppma
Oxygen Content
1ppma
Particles
<50 @ 0.3um
Grade
Test Grade



Dia 50.8mm Size IC Silicon Wafer , N Type 300mm Silicon Wafer Si Single Crystal MaterialDia 50.8mm Size IC Silicon Wafer , N Type 300mm Silicon Wafer Si Single Crystal Material
