Dia 50.8mm 2 Inch Sapphire Substrate Thickness 100um By C Orientation

Place of Origin china
Brand Name zmsh
Model Number 0.1mm 2inch
Minimum Order Quantity 25pcs
Price by case
Packaging Details Vacuum-sealed containers with nitrogen backfill in a class 100 environment
Delivery Time 10-30days
Payment Terms Western Union, T/T
Supply Ability 10000pcs/months
Product Details
Material 99.999% Al2O3 Industry Led,optical Glass,eli-ready Wafer
Application Semicondutor Wafer, Led Chip, Optical Glass Window, Electronic Ceramics Color White Or Red Or Blue
Vision Light Transmissivity 85% Advantagement High Hardness9.0,wear Resistance,
Type Single Crystal
High Light

sapphire substrate

,

custom sapphire glass

Leave a Message
Product Description
ultrathin sapphire glass wafer ,2inch 0.1mm thickness sapphire wafer, 10x10x0.1mmt sapphire substrates, <0001> orientation dia50.8x0.1mmt sapphire wafers


We can supply professional customized service in time and provide cooperation and support of new product development and technology appliance.

2inch 0.1mm thickness sapphire wafer specification
Material: Single crystal Al2O3 99.999%
Orientation: C-plane(0001) Off M -axis 0.2°±0.1

Diameter:50.80±0.2mm
Thickness :100±15um (80um also is ok)
Primary flat:16±1mm (or round wafer)

OF Orientation flat: A axis±0.1°
Frontside Surface Roughness:Ra<0.3nm
Backside Surface Roughness: 0.8~1.2um
( Or double side polished, both side Ra<0.2nm)
TTV:<10um BOW:-15~0um WARP:<10um
Laser Mark Series No. by needs
Package:Vacuum-sealed containers with nitrogen backfill in a class 100 environment

Cleanliness :Free visible contamination



Applications
Sapphire Washers, Sapphire Windows, Sapphire Bearings, Sapphire Rods, Sapphire Tubes, Ruby
sapphire wafer, dome sapphire, Sapphire insulation Film, Sapphire ball lens, Sapphire/ruby ball


Dia 50.8mm 2 Inch Sapphire Substrate Thickness 100um By C Orientation 0

Chemically, sapphire is single crystal aluminum oxide (Al2O3), and is useful in a transmission range from 0.2 - 5.5µm.Sapphire , so making them ideal materials for demanding applications (such as laser systems) because of their extreme surface hardness, high thermal conductivity, high dielectric constant and resistance to common chemical acids and alkalis. And sapphire also is the second hardest crystal next to diamonds and, because of their structural strength, sapphire windows can be made much thinner than other common dielectric windows with improved transmittance.


Sapphire Wafer Process Step
Dia 50.8mm 2 Inch Sapphire Substrate Thickness 100um By C Orientation 1

Sample
Dia 50.8mm 2 Inch Sapphire Substrate Thickness 100um By C Orientation 2


 we also can provide other materials crystal seimconductor wafers as like  GaN, SiC,GaAs,InP,MgO etc.


Packing & Delivery

Packing Details : Packing, BOX,CARTONS by 25pcs cassette in cleaning room by vacuumize

Delivery Details : 3-10  days after order of Solid bicycle tire tubesrecieving your pament will be send out.
