Product Details
Place of Origin: china
Brand Name: zmsh
Model Number: 2inch A-AXIS
Payment & Shipping Terms
Minimum Order Quantity: 25pcs
Price: by case
Packaging Details: Vacuum-sealed containers with nitrogen backfill in a class 100 environment
Delivery Time: 10-20days
Payment Terms: Western Union, , T/T
Supply Ability: 1000pcs/months
Material: |
99.999％ Al2O3 |
Industry: |
Led，optical Glass，eli-ready Wafer |
Application: |
Semicondutor Wafer, Led Chip, Optical Glass Window, Electronic Ceramics |
Color: |
White Or Red Or Blue |
Vision Light Transmissivity: |
85％ |
Advantagement: |
High Hardness9.0，wear Resistance, |
Type: |
Single Crystal |
Orientation: |
R-plane |
Material: |
99.999％ Al2O3 |
Industry: |
Led，optical Glass，eli-ready Wafer |
Application: |
Semicondutor Wafer, Led Chip, Optical Glass Window, Electronic Ceramics |
Color: |
White Or Red Or Blue |
Vision Light Transmissivity: |
85％ |
Advantagement: |
High Hardness9.0，wear Resistance, |
Type: |
Single Crystal |
Orientation: |
R-plane |
2inch A-axis <11-20> orientation sapphire wafer for epi-ready test ,sapphire optical windows, m-axis,c-axis, R-axis 2inch sapphire epi-ready substrate
1. Description
Sapphire is one of the hardest materials, and possesses very good transmission during the range of visible and near IR spectrum.It is widely used as optical window in infrared and far infrared military equipments, apparatus and instruments of satellite and space technology, and navigation and spaceflight, such as night infrared scope/sight and night vision camera, etc.The sapphire crystal window is intensively applied in high-tech fields.
Sapphire optical windows are ideal for applications where high pressure, vacuum, or corrosive atmospheres are a consideration. Sapphire, a single crystal form of Al2O3, is resistant to attack by strong acids due to its high dielectric constant. It has high compressive strength and a high melting point. It is also resistant to UV radiation darkening.
sapphire application: sapphire optical lens ,sapphire ball, sapphire bearing ,sapphire led wafer, sapphire watch glass lens.
2. QC Standard
3. FAQ:
1. Can you accept OEM?
Yes!.We can manufacture as per your request specification.
2. Can you deliver the goods via our shipping agent?
Yes, we could help you make the delivery using your shipping agent
3. What about your After-sales service?
Yes.We promise that we can change or refund products if there are any quality problem.
If you need more professional help, please contact us. Our technical engineers
would like to give advices according to your requirements
Specification:
Single crystal Al2O3 99.999％
Orientation: A-axis 0.5°
Diameter:50.8±0.1mm
Thickness :430±15um or 330±15um
Primary flat:16±1mm
OF Orientation flat: C axis ±0.1° C-plane(0001)
Frontside Surface Roughness:Ra＜0.2nm
Backside Surface Roughness: 0.8~1.2um ( Or double side polished, both side Ra＜0.2nm)
TTV:＜15um BOW:-15~0um WARP:＜15um
Laser Mark Series No. by needs
Package:Vacuum-sealed containers with nitrogen backfill in a class 100 environment
Cleanliness :Free visible contamination
we also provide other materials semiconductor wafer as likes SiC, GaN, GaAs, InP .
