6inch VGF Method N Type GaAs Substrates 2 degree Off 675um SSP Wafers

Place of Origin china
Brand Name zmsh
Certification ROHS
Model Number 6INCH GaAs wafer
Minimum Order Quantity 10pcs
Price by case
Packaging Details PET film in 100-grade cleaning room
Delivery Time 1-4weeks
Supply Ability 500pcs/month
Product Details
Material MONOcrystal GaAs Industry Semicondutor Wafer For Ld Or Led
Application Semiconductor Substrate, Led Chip, Optical Glass Window,device Substrates Method CZ
Size 2inch~6inch Thickness 0.675mm
Surface Cmp/etched Doped Si-doped
MOQ 10PCS
High Light

VGF Method Gallium Arsenide Substrate

,

N Type GaAs Substrates

,

2 Degree GaAs Epi Wafer

Leave a Message
Product Description

2inch 3inch 4inch  6inch VGF method N-Type  un-doped  GaAs substrates 2degree off 675um SSP DSP GaAs wafers
------------------------------------------------------------------------------------------------------------------------------

GaAs wafer (Gallium Arsenide) is an advantageous alternative to silicon that has been evolving in the semiconductor industry. Less power consumption and more efficiency offered by this GaAs wafers are attracting the market players to adopt these wafers, thereby increasing the demand for GaAs wafer. Generally, this wafer is used to manufacture semiconductors, light emitting diodes, thermometers, electronic circuits, and barometers, besides finding application in the manufacturing of low melting alloys. As the semiconductor and electronic circuit industries continue to touch new peaks, the GaAs market is booming. Gallium arsenide of GaAs wafer has the power of generating laser light from electricity. Especially polycrystalline and single crystal are the two major type of GaAs wafers, which are utilized in the production of both the microelectronics and optoelectronics to create LD, LED, and microwave circuits. Therefore, the extensive range of GaAs applications, particularly in optoelectronics and microelectronics industry is creating a demand influx in the GaAs Wafer Market. Previously, the optoelectronic devices were mainly used on a broad range in short-range optical communications and computer peripherals. But now, they are in demand for some emerging applications such as LiDAR, augmented reality, and face recognition. LEC and VGF are two popular methods which are improving the production of GaAs wafer with high uniformity of electrical properties and excellent surface quality. Electron mobility, single junction band-gap, higher efficiency, heat and moisture resistance, and superior flexibility are the five distinct advantages of GaAs, which are improving the acceptance of GaAs wafers in the semiconductor industry.

Specification detail
6inch VGF Method N Type GaAs Substrates 2 degree Off 675um SSP Wafers 0
GaAs (Gallium Arsenide) for LED Applications
Item Specifications Remarks
Conduction Type SC/n-type
Growth Method VGF
Dopant Silicon
Wafer Diamter 2, 3 & 4 inch Ingot or as-cut available
Crystal Orientation (100)2°/6°/15° off (110) Other misorientation available
OF EJ or US
Carrier Concentration (0.4~2.5)E18/cm3
Resistivity at RT (1.5~9)E-3 Ohm.cm
Mobility 1500~3000 cm2/V.sec
Etch Pit Density <500/cm2
Laser Marking upon request
Surface Finish P/E or P/P
Thickness 220~350um
Epitaxy Ready Yes
Package Single wafer container or cassette



GaAs (Gallium Arsenide) ,Semi-insulating for Microelectronics Applications



Item
Specifications
Remarks
Conduction Type
Insulating

Growth Method
VGF

Dopant
Undoped

Wafer Diamter
2, 3, 4 & 6 inch
Ingot available
Crystal Orientation
(100)+/- 0.5°

OF
EJ, US or notch

Carrier Concentration
n/a

Resistivity at RT
>1E7 Ohm.cm

Mobility
>5000 cm2/V.sec

Etch Pit Density
<8000 /cm2

Laser Marking
upon request

Surface Finish
P/P

Thickness
350~675um

Epitaxy Ready
Yes

Package
Single wafer container or cassette

No. Item Standard Specification
1 Size   2" 3" 4" 6"
2 Diameter mm 50.8±0.2 76.2±0.2 100±0.2 150±0.5
3 Growth Method   VGF
4 Doped   Un-doped, or Si-doped, or Zn-doped
5 Conductor Type   N/A, or SC/N, or SC/P
6 Thickness μm (220-350)±20 or (350-675)±25
7 Crystal Orientation   <100>±0.5 or 2 off
OF/IF Orientation Option   EJ, US or Notch
Orientation Flat (OF) mm 16±1 22±1 32±1 -
Identification Flat (IF) mm 8±1 11±1 18±1 -
8 Resistivity (Not for
Mechanical
Grade)
Ω.cm (1-30)´107, or (0.8-9)´10-3, or 1´10-2-10-3
Mobility cm2/v.s ≥ 5,000, or 1,500-3,000
Carrier Concentration cm-3 (0.3-1.0)x1018, or (0.4-4.0)x1018,
or As SEMI
9 TTV μm ≤10
Bow μm ≤10
Warp μm ≤10
EPD cm-2 ≤ 8,000 or ≤ 5,000
Front/Back Surface   P/E, P/P
Edge Profile   As SEMI
Particle Count   <50 (size>0.3 μm,count/wafer),
or AS SEMI
10 Laser Mark   Back side or upon request
11 Packaging   Single wafer container or cassette
