Arc France Growth Cube Crystal Mgo Substrates , Magnesium Oxide Crystal

Arc France Growth Cube Crystal Mgo Substrates , Magnesium Oxide Crystal

  • High Light

    Arc France mgo substrates

    ,

    Cube crystal mgo substrates

    ,

    mgo magnesium oxide crystal

  • Materials
    MgO Single Crystal
  • Industry
    Semiconductor Substrates,device,
  • Color
    WHITE
  • Crystal Structure
    Cube
  • Density
    3.58
  • Size
    10x10,20x20,5x5mmt
  • Polished
    DSP/ SSP OK
  • Place of Origin
    CHINA
  • Brand Name
    zmkj
  • Model Number
    MgO-001
  • Minimum Order Quantity
    10pcs
  • Price
    by case
  • Packaging Details
    single wafer case
  • Delivery Time
    1-4weeks
  • Supply Ability
    1000pcs/month

Arc France Growth Cube Crystal Mgo Substrates , Magnesium Oxide Crystal

MgO substrates,10X10mm MgO wafer,semiconductor wafer,Magnesium oxide (MgO) crystal substrate, crystals supplier MgO WAFER 5x5mm

Product Description:
Magnesium oxide (MgO) is excellent for monocrystalline substrate is widely used in production of the ferroelectric thin film,
he magnetic film, optical film and the high-temperature superconducting thin film, etc., as it is in the microwave band dielectric constant and loss are small, and can obtain a large area of a substrate (a diameter of 2 inches and larger), it is the current industry, an important high-temperature superconducting thin film of single-crystal substrates. Can be used to make mobile communication equipment required for high-temperature superconducting microwave filters and other devices. we  are discharge using a special high purity growth size of about 2 "x2" x 1 ", low-cost single crystal MgO, prepared by chemical mechanical polishing the surface of high quality substrates atomically.

Technical parameters:



Crystal structure Cube
Lattice constant a = 4.216Å
Growth method Arc France
Mp 2850 °C
Density 3.58g/cm3
Mohs hardness 5.5 Mohs
Thermal expansion coefficient 12.8 × 10 -6 / °C
Permittivity 9.8
Optical transmission
> 90% @ 200 ~ 400 nm> 98% 500 ~ 1000 nm
Crystal cleavage plane
<100>
Specifications:

<100>, <110>, <111> Tolerance: + / -0.5 degrees
dia2 "x0.5mm, 10x10x0.5mm, 15x15x0.5mm,10x3mmt,10x5mmt,20X15mmt,20x20mmt,
Single side polished or double 2sp, Ra <5A
Note: according to customers' requirements and size of the corresponding direction.

Standard Packaging: 1000 clean room, 100 clean bag or single box packaging



Arc France Growth Cube Crystal Mgo Substrates , Magnesium Oxide Crystal 0

Arc France Growth Cube Crystal Mgo Substrates , Magnesium Oxide Crystal 1

FAQ:
Q: Do you have standard products?
A: Our standard products on standard orientation in stock.



Q: What's your MOQ?
A: (1) For inventory, the MOQ is 10pcs.
(2) For customized products, the MOQ is 25pcs up.



Q: What's the way of shipping and cost?
A:(1) We accept DHL, Fedex, EMS etc.
(2) If you have your own express account, it's great.If not,we could help you ship them.
Freight is in accordance with the actual settlement.
Q: How to pay?
A: 100%T/T, Paypal, Secure payment and Assurance payment .
Q: What's the delivery time?
A: (1) For the standard products
For inventory: the delivery is 5 workdays after you place the order.
For customized products: the delivery is 2 or 3 weeks after you place the order.

Q: Can I customize the products based on my need?
A: Yes, we can customize the material, specifications,shape,thickness by your need.
