55mm/1010mm Silicon Carbide Wafer Thickness 350μm Sic 3C-N Type High Mechanical Strength Production Grade

Name: 5*5mm/10*10mm Silicon Carbide Wafer Thickness 350μm Sic 3C-N Type High Mechanical Strength Production Grade
Brand: ZMSH
SKU: 3C-N SiC
Rating: 4.7 (139 reviews)

Product Details

Place of Origin: CHINA

Brand Name: ZMSH

Certification: rohs

Model Number: 3C-N SiC

Payment & Shipping Terms

Minimum Order Quantity: 10pc

Price: by case

Packaging Details: customzied plastic box

Delivery Time: in 30days

Payment Terms: T/T

Supply Ability: 1000pc/month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                350μm Silicon Carbide Wafer, Sic 3C-N Type  Silicon Carbide Wafer, High Mechanical Strength Silicon Carbide Wafer


Size:	55mm/1010mm	Dielectric Constant:	9.7
Surface Hardness:	HV0.3>2500	Density:	3.21 G/cm3
Thermal Expansion Coefficient:	4.5 X 10-6/K	Breakdown Voltage:	5.5 MV/cm
Applications:	Communications, Radar Systems

Size:	55mm/1010mm
Dielectric Constant:	9.7
Surface Hardness:	HV0.3>2500
Density:	3.21 G/cm3
Thermal Expansion Coefficient:	4.5 X 10-6/K
Breakdown Voltage:	5.5 MV/cm
Applications:	Communications, Radar Systems

5*5mm/10*10mm Silicon Carbide Wafer Thickness 350μm Sic 3C-N Type High Mechanical Strength Production Grade

Product Description:

55mm/1010mm Silicon Carbide Wafer Thickness 350μm Sic 3C-N Type High Mechanical Strength Production Grade

3C-SiC (Cubic Silicon Carbide) is a wide bandgap semiconductor material with good electrical and thermal properties, especially suitable for high-frequency, high-power and electronic device applications. N-type doping is usually achieved by introducing elements such as nitrogen (N) and phosphorus (P), which makes the material electronegative and suitable for a variety of electronic device designs. The bandgap is approximately 3.0 eV, making it suitable for high temperature and high voltage applications. N-type doping still maintains high electron mobility, which enhances the performance of the device. Excellent thermal conductivity helps to improve the heat dissipation ability of power devices. It has good mechanical strength and is suitable for use in harsh environments. It has good resistance to a wide range of chemicals and is suitable for industrial applications. In power electronics, it is used in high-efficiency power converters and drives, suitable for electric vehicles and renewable energy systems.

Features:

· Wide bandgap: Bandgap of approximately 3.0 eV for high temperature and high voltage applications.

· High Electron Mobility: N-type doping provides good electron mobility and enhances the overall performance of the device.

· Excellent thermal conductivity: It has excellent thermal conductivity and effectively improves heat dissipation performance, suitable for high-power applications.

· Good mechanical strength: It has high toughness and compressive strength, and is suitable for use in harsh environments.

· Chemical resistance: Good resistance to a wide range of chemicals, enhancing the stability of the material.

· Adjustable electrical characteristics: By adjusting the doping concentration, different electrical properties can be achieved to meet the needs of a variety of applications.

Technical Parameters:

5*5mm/10*10mm Silicon Carbide Wafer Thickness 350μm Sic 3C-N Type High Mechanical Strength Production Grade 4

Applications:

1. Power electronics: for high-efficiency power converters, inverters and drives, widely used in electric vehicles and renewable energy systems.

2. RF & Microwave Equipment: RF amplifiers, microwave equipment, especially suitable for communication and radar systems.

3. Optoelectronics: It can be used as a building block for LEDs and light detectors, especially in blue and ultraviolet applications.

4. Sensors: Applied to a wide range of sensors in high-temperature and high-power environments, providing reliable performance.

5. Wireless Charging and Battery Management: Used in wireless charging systems and battery management devices to improve efficiency and performance.

6. Industrial electrical equipment: Used in industrial automation and control systems to improve energy efficiency and system stability.

Customization:

Our SiC substrate is available in the 3C-N type and is RoHS certified. The minimum order quantity is 10pc and the price is by case. The packaging details are customized plastic boxes. The delivery time is within 30 days and we accept T/T payment terms. Our supply ability is 1000pc/month. The SiC substrate size is 55mm/1010mm. Place of origin is China.
