Rectangle C Axis Sapphire Optical Glass Lens Customized Shape For Protective Glass

size213x116x5mmt rectangle C axis sapphire optical glass window,customized shape sapphire glass for protective glass

1. Sapphire description

Sapphire optical windows are ideal for applications where high pressure, vacuum,

or corrosive atmospheres are a consideration. Sapphire, a single crystal form of Al2O3,

is resistant to attack by strong acids due to its high dielectric constant.

It has high compressive strength and a high melting point. It is also resistant to UV radiation darkening.

sapphire process step

Sapphire crystal body(Ky) ---->Customized axis ingot/block----> 1st anneal ---->wire saw cut

---->repair shape----->rough lap--->charmfer---->fine grind---->polishing---->inspection---package

sapphire compare with other optical materials

• Mechanically second only to diamond. One of the hardest and most scratch resistant materials
available. The high modulus of elasticity and high tensile strength make it extremely wear,
abrasion and impact resistant.
• Colorless optical characteristics are superior to any standard glass, with up to a 98.5%
transmission and a transmission window from 190 nanometers in the UV to 5 microns in the IR.
• No solarization in high-radiation systems.
• High dielectric constant and low loss tangent makes it a great electrical insulator and low
loss long wavelength window.
• Thermally very stable. Does not lose any of its mechanical and optical qualities from cryogenic
to over 2000C.
• Thermal conductivity greater than other optical materials and most dielectrics.
• No surface damage and devitrification due to extreme thermal cycling
• Does not sag or slump at very elevated temperatures.
• Highly corrosion resistant. More resistant to corrosive chemicals than most standard hard
materials available.


Property  Specification
Thickness                     0.08-200mm
Size tolerance:              0.01mm
Edge Finish:                Ground and beveled
Surface Quality           40-20 scratch-dig or 60/40,20/10,
Surface Flatness         λ/4 @ 633 nm~2λ
Parallelism                  ≤3 arc min (≤0.9 mrad)
Clear Aperture            >80% of central diameter
Hardness (Knoop)        1370 kg mm-2
Young's modulus          3.4 x 1011 N m-2
Thermal Limit               22 W m-1 K-1
Thermal expansion coefficient    8.4 x 10-6 K-1

Our company grow the sapphire single crystal by KY method,we can supply sapphire ingot(2inch,4inch,6inch,8inch),sapphire wafer(single/double side polishing),sapphire block,

all kinds of sapphire optical window(applied to optical equipment,industry camera,

cell phone watches and other special optical components),if you have any requirements,

please contact us,looking forward to your cooperation.

3.Pictures  Size For Sapphire Lens

Materials: 99.999％ sapphire optical grade ,no bubble ,color and crystal boundar.

size:length205x120x2.0mmt

Orientation:C(0001)±1°,

Tolerance:±0.05mm

surface: double side poshlied

Ra:＜0.5nm

SD:40/20
